Features

Applications

Low Insertion Loss

Fiber Laser Cutting

High Return Loss

Mopa Fiber Laser

High Isolation

Fiber Laser Marking

High stability & Reliability

Fiber Amplifier

Specifications

Parameters

Unit

Value

Center Wavelength

nm

1064 or Specified

Operating Wavelength Range

nm

±5

Typ. Peak Isolation at 23℃

dB

30~35

Min. Isolation at 23℃

dB

28

Max. Insertion Loss at 23℃

dB

0.5

Max. Polarization Dependent Loss at 23℃, only for PI

dB

0.1

Min. Beam Roundness

%

90

Min. Return Loss(Input /Output)

dB

50

Nominal Output Beam Diameter (1/e2 )

mm

7±1 or Specified

Max. Average Optical Power

W

10, 20 or Specified

Max. Peak Power for ns Pulse

kW

10 or Specified

Max. Tensile Load

N

5

Operating Temperature

℃

+5~+55

Storage Temperature

℃

-5~+75

   HPCI-1111-2-333-4567-8899

1064

-Center Wavelength:

1064=1064nm ,SSSS=specify

2

-Beam Diameter：

7=7mm,

333

-Fiber Type:

021=LMA-GDF-20/130-M, 031=LMA-GDF-30/250-M, S=Specified

4

-Package Dimension:

0=75.5x42x42mm

5

-Armoured Cable Length:

1=1m Armoured cable, 2=2m Armoured cable, S=Specified

6

-Fiber Tube Length:

1=1m 900um loose tube,

7

-Fiber Length:

1=1m,2=m,S=Specified

88

-Average Power:

10=10W,20=20W,S=Specified+

99

-Pulse Power:

10=10K, 20=20K
